技术参数
| 货号 |
测量范围 |
分辨力 (mm/in) |
爪长 |
精度 |
| 17-501A |
0-500mm |
0.01/0.0005" |
100mm |
±0.05mm |
| 17-501B |
0-500mm |
0.01/0.0005" |
125mm |
±0.05mm |
| 17-501C |
0-500mm |
0.01/0.0005" |
150mm |
±0.08mm |
| 17-601A |
0-600mm |
0.01/0.0005" |
100mm |
±0.05mm |
| 17-601B |
0-600mm |
0.01/0.0005" |
125mm |
±0.05mm |
| 17-601C |
0-600mm |
0.01/0.0005" |
150mm |
±0.08mm |
| 17-801A |
0-800mm |
0.01/0.0005" |
125mm |
±0.06mm |
| 17-801B |
0-800mm |
0.01/0.0005" |
150mm |
±0.06mm |
| 17-801C |
0-800mm |
0.01/0.0005" |
200mm |
±0.09mm |
| 17-102A |
0-1000mm |
0.01/0.0005" |
125mm |
±0.07mm |
| 17-102B |
0-1000mm |
0.01/0.0005" |
150mm |
±0.07mm |
| 17-102C |
0-1000mm |
0.01/0.0005" |
200mm |
±0.10mm |
| 17-152A |
0-1500mm |
0.01/0.0005" |
125mm |
±0.11mm |
| 17-152B |
0-1500mm |
0.01/0.0005" |
150mm |
±0.11mm |
| 17-152C |
0-1500mm |
0.01/0.0005" |
200mm |
±0.15mm |
| 17-202A |
0-2000mm |
0.01/0.0005" |
150mm |
±0.14mm |
| 17-202B |
0-2000mm |
0.01/0.0005" |
200mm |
±0.14mm |
| 17-202C |
0-2000mm |
0.01/0.0005" |
300mm |
±0.20mm |
| 17-252A |
0-2500mm |
0.01/0.0005" |
150mm |
±0.22mm |
| 17-252B |
0-2500mm |
0.01/0.0005" |
200mm |
±0.22m |
| 17-252C |
0-2500mm |
0.01/0.0005" |
300mm |
±0.25mm |
| 17-302A |
0-3000mm |
0.01/0.0005" |
150mm |
±0.26mm |
| 17-302B |
0-3000mm |
0.01/0.0005" |
200mm |
±0.26mm |
| 17-302C |
0-3000mm |
0.01/0.0005" |
300mm |
±0.30mm | |
